This is a guage set to augment the basic instruments in a 2002 Honda s2000. The gauges are desinged with a similar look to blend in. There are two types of visual styles, simple and complex. The complex looks is designed to emulate the s2000 tachometer, but is split in the center so that two elements can be shown in each gauge. (The line down the center of each arc can be removed, I put it in becuase I thought it looked better).

The simpler gauges are a little brighter, I'm still expirimenting with the color combinations.

The easiest way to change pages is to tap the lower corners of the screen, I've added controls that are not visibile until pressed.

There is no tach, speedometer as these are well represented in the main dashboard already. The first page has six gauges:

1. Intake temp and coolant temp. Pressing this gauge cycles the number at the center of the gauge between these two items.

2. Fuel trims. For some alien, unknown reason, the s2000 has two fuel banks, 1 and 3. This gauge cycles between banks 1 and 3, showing either short or long term in the center display.

3. Fuel use: this shows instant and average fuel use.

4. A clock. I'm using the correct string to show a leading zero on the minutes, but it's not showing up in Dash Commander, so for now 12:01 shows up as 12:1.

5. (line gauges at the center of the display): Spark advance and vacuum/boost. For those of you with forced induction, it'll show boost as positive pressure.

The second page has individual gagues that do not change. Short and long fuel trims for banks 1 and 3, a clock, spark advance and boost/vac. Useful for checking all the items at a glance.
